Product Details:
| Place of Origin: | Industrial Chiller Factory |
| Brand Name: | AODE |
| Certification: | ISO, CE, ROHS |
| Model Number: | AC-260WD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $ |
| Packaging Details: | Protective/air bubble film, Wooden case. As client’s require |
| Delivery Time: | Within 20days after receiving |
| Payment Terms: | 30% T/T in advance, 70% balanc |
| Supply Ability: | 500pcs/month |
Plastic Injection Molding Water Cooled Screw Chiller Cooling Machine Water Cooled Screw Chiller by AODE is a high-performance industrial cooling solution designed for plastic injection molding and extruder applications. With a semi-enclosed screw-type compressor and a cooling capacity of 223,600 Kcal/h, it offers 7-35℃ temperature control with ±2℃ precision. Certified with CE and ISO, the chiller is equipped with safety features, including high/low pressure protection and low water flow/temperature alarms, making it the ideal choice for heavy-duty cooling.
| Product Name: | Water Cooled Screw Chiller | Brand Name: | AODE |
|---|---|---|---|
| Application: | Plastic Injection Molding|Extruder | Certification: | CE|ISO |
| Compressor Type: | Semi-enclosed Screw-type | Power Input: | 60KW |
| Power Supply: | 3N-50HZ-380V | Temperature Range: | 7-35℃ |
| Theory: | Water Cooled | ||
| High Light: | Water Cooled Screw Chiller, 3N-50HZ-380V Water Cooled Screw Chiller, Plastic Injection Molding Water Cooled Screw Chiller | ||
High Refrigerating Capacity: Offers an impressive 223,600 Kcal/h cooling capacity, perfect for large-scale applications.
Semi-enclosed Screw-type Compressor: Provides efficient and reliable cooling.
Precision Temperature Control: Temperature range: 7-35℃, with ±2℃ precision for consistent performance.
Energy Efficiency: The high-efficiency evaporator and condenser help save up to 30% energy.
Safety Features: Includes high/low pressure protection, overheating protection, and anti-frost protection.
Top-Quality Components: Utilizes Danfoss thermostatic valves, OMRON electrical devices, and Stainless steel heat exchangers.
ITEM | UNIT | AC-260WD | |
Refrigerating capacity | Kcal/h | 223600 | |
KW | 260 | ||
Input water | KW | 60 | |
Maximum Running Current | A | 102 | |
Energy adjust range | % | 100-75-50-25-0 | |
Power supply | 3N-50HZ-380V | ||
R22 Refrigerant | Filling Volume | kg | 22×2 |
Control mode | Thermostatic External valve | ||
Compressor | Model | Semi-enclosed screw-type | |
Power | Kw | 30×2 | |
Evaporator | Model | Shell and Tube | |
Chilled water flow | M3/h | 44.7 | |
Water resistance | Kpa | 39 | |
Water inlet/outlet diameter | DN | 80.0 | |
Condenser | Model | Shell and Tube | |
Chilled water flow | M3/h | 58.1 | |
Water resistance | Kpa | 45 | |
Water inlet/outlet diameter | DN | 80 | |
Protecting equipment | High/Low Pressure switch, Anti-frost Protector, Fusible Plug, Overload Protector, Motor Overheat Protector, Automatic Temperature Sensitive Switch, Anti-phase Protector | ||
Size(L×W×H) | mm | 3000×750×1900 | |
Weight | kg | 2250 | |
Running Weight | Kg | 2750 | |
Plastic Injection Molding: Ensures stable, reliable cooling for mold temperature control.
Extruder Machines: Perfect for maintaining consistent temperature during extrusion processes.
Aluminum & Magnesium Alloy Processing: Ideal for cooling during alloy production in automotive and electronic manufacturing.
Die Casting: Optimizes die-casting operations by maintaining consistent temperatures.
Chemical & Industrial Manufacturing: Efficiently cools chemical reactors, mixing tanks, and other heavy-duty systems.
Energy Efficient: Saves over 30% in energy consumption through high-efficiency heat exchangers.
Precise Temperature Control: Guarantees ±2℃ precision in temperature control for sensitive applications.
Durable & Reliable: Built with top-grade components and designed for long-lasting, safe operation.
Easy Maintenance: Includes fault displays and user-friendly features for simple maintenance and repair.
Comprehensive Protection: Multiple safety features, including high/low pressure protection, ensure safe operation.
Versatile Application: Perfect for plastic injection molding, die casting, extruders, and other industrial processes.
The chiller has a cooling capacity of 223,600 Kcal/h, making it suitable for large-scale industrial applications.
It offers a temperature range of 7-35℃, with precision control of ±2℃ for reliable cooling.
The chiller features a semi-enclosed screw-type compressor, known for its efficiency and durability.
The chiller is equipped with high-efficiency evaporators and condensers, resulting in up to 30% energy savings.
It includes high/low pressure protection, overheating protection, anti-frost protection, and low water flow/temperature alarms.
This chiller is ideal for plastic injection molding, extruders, die casting, chemical processing, and other heavy-duty industrial cooling applications.
